TS 400
thin-cutting horizontal band resaw
Eliminating the conventional spring laded pressure
rollers, this machine employs air loaded pressure
rollers. Especially when cutting wood of various
thicknesses, the air load saves time on adjusting
pressure roller position while increasing operational
convenience. Pressure roller are easily adjuste in the
vertical directions to suit various wood thicknesses.

TS 400 SPECIFICATIONS
Max. cutting capacity 420x200 mm

Distance from blade to conveyor 2-150 mm
Min. cutting thickness 2mm
Saw wheel diam. 800 mm.
Sawblade lenght 5500 mm.
Sawblade width 2”
Oil mist cooling system

High accuracy hydraulic blade tension system
Variable feed speed 0-25 m/min
Feed motor Hp 2 with inverter
Main motor with inverter 30 Hp
Blade lift motor 0,5 Hp

Dust hood outlet diam. 100mm.x2
Weight Kg. 3100

HBR 400
thin-cutting horizontal bandsaw
Digital readout assures high accuracy cutting and
convenient thickness control. Variable speed is
controlled by a frequency inverter and displayed on the
control panel. Movable control box permits convenient
operation control at any position. The pressure roller
motion is controlled by an infrared ray sensor.
HBR 400 SPECIFICATIONS
Max. cutting capacity 420x250 mm
Distance from blade to conveyor 5-270 mm
Min. cutting thickness 3mm
Saw wheel diam. 800 mm.
Sawblade lenght 5860-5870 mm.

Sawblade width 2”
Sawblade speed 6150 rpm
Conveyor belt sizes 400x4200 mm
Variable feed speed 0-30 mt/min
Return conveyor size 2550x630x825 mm
Main motor with inverter 30 Hp

Blade lift motor 0,5 Hp
Dust hood outlet diam. 100mm.x2
Weight Kg. 2250
